Hexagonal Hole Perforated Metal
Hexagonal hole perforated metal is manufactured by punching precise hexagonal openings into metal sheets. The hexagonal pattern provides a high open area while maintaining excellent structural strength, making it ideal for ventilation, screening, decorative, and architectural applications.
Maidong supplies custom hexagonal hole perforated metal sheets in stainless steel, aluminum, galvanized steel, and carbon steel with various hole sizes, pitches, and thickness options.
What Is Hexagonal Hole Perforated Metal?
Hexagonal hole perforated metal is produced by punching uniform hexagonal openings into metal sheets using precision perforating equipment. The honeycomb-like pattern provides an excellent balance between high open area, lightweight construction, and structural strength.
Compared with round and square perforated sheets, hexagonal perforations can achieve larger open areas while maintaining good rigidity, making them suitable for ventilation, screening, decorative, and architectural applications.
Available in stainless steel, galvanized steel, aluminum, and carbon steel, hexagonal hole perforated metal is widely used in facades, protective covers, ventilation panels, acoustic systems, and industrial equipment.
Specifications of Hexagonal Hole Perforated Metal
Hexagonal hole perforated sheets are available in various hole sizes, materials, thicknesses, and open area configurations for industrial and architectural applications.
| Specification | Available Range |
|---|---|
| Material | Stainless Steel 304, 316, Carbon Steel, Galvanized Steel, Aluminum |
| Hole Size | 2mm – 100mm |
| Sheet Thickness | 0.3mm – 10mm |
| Open Area | 20% – 80% |
| Sheet Width | Up to 1500mm |
| Sheet Length | Up to 3000mm |
| Hole Pattern | Hexagonal Pattern |
| Surface Finish | Mill Finish, Powder Coated, PVDF Coating |
| Processing Service | Cutting, Bending, Welding, Rolling |
Click the button below to download the detailed specification sheet.
Perforated Metal Technical Specifications
| Material | Thickness Range | Hole Diameter | Hole Pattern | Open Area | Standard Sheet Size | Applications |
|---|---|---|---|---|---|---|
| Stainless Steel 304 / 316 | 0.3–6.0 mm | 0.5–50 mm | Round, Slotted, Square, Hexagonal | 20%–70% | 1000×2000 mm, 1220×2440 mm, Custom | Filtration, ventilation, machine guards |
| Aluminum | 0.5–5.0 mm | 1–50 mm | Round, Slotted, Decorative | 25%–65% | 1000×2000 mm, 1220×2440 mm, Custom | Architectural panels, ceilings, decoration |
| Galvanized Steel | 0.5–6.0 mm | 1–60 mm | Round, Slotted, Square | 20%–60% | 1000×2000 mm, 1220×2440 mm, Custom | Protective covers, fencing, ventilation |
| Carbon Steel | 0.8–8.0 mm | 2–80 mm | Round, Slotted, Square | 20%–60% | Custom sheet size available | Heavy-duty protection, screening, industrial use |
Applications of Hexagonal Hole Perforated Metal
Hexagonal hole perforated metal combines high open area, lightweight construction, and modern appearance, making it suitable for both industrial and architectural applications.
Architectural Facades
The honeycomb pattern creates an attractive visual effect while providing ventilation and sun shading for modern buildings.
Ventilation Panels
The large open area allows excellent airflow, making it suitable for HVAC systems and equipment enclosures.
Acoustic Panels
Hexagonal perforations can be used in sound absorption and noise reduction systems for commercial and industrial buildings.
Machine Guards
Provides protection while maintaining visibility and airflow around equipment.
Decorative Panels
Widely used in interior decoration, ceiling systems, wall cladding, and partition panels.
Protective Covers
Suitable for fan covers, speaker grilles, and equipment protection applications.
Industries Served
- Architecture
- Interior Decoration
- Industrial Manufacturing
- HVAC Systems
- Commercial Construction
- Equipment Manufacturing
Why Choose Hexagonal Holes?
Compared with traditional perforation patterns:
✅ Higher Open Area
✅ Better Airflow Performance
✅ Modern Decorative Appearance
✅ Lightweight Structure
✅ Excellent Strength-to-Weight Ratio
Open Area & Design Features
Hexagonal hole perforated metal is known for its high open area and honeycomb structure, which provide excellent airflow and lightweight performance.
The open area percentage can be adjusted according to ventilation, decorative, or structural requirements.
| Open Area | Typical Application |
|---|---|
| 20% – 35% | Protective Covers |
| 35% – 50% | Industrial Ventilation |
| 50% – 65% | Architectural Facades |
| 65% – 80% | Decorative Panels |
Custom Manufacturing Available
Maidong can manufacture hexagonal hole perforated sheets with customized:
- Hole Size
- Open Area
- Sheet Thickness
- Material Grade
- Panel Dimensions
according to customer drawings and project requirements.
